RF PCB process capability
| Biggest size: | 1190mm*490mm |
|---|---|
| Number of layers: | Single-sided AL-substrate, double-sided AL-substrate |
| Thermal Conductivity: | 1.0-2.0 |
| Minimum Trace Distance: | 8mil（0.2mm） |
| Drilling Hole Tolerance: | ±0.1mm |
| Minimum Trace Width | ≥10mil | Copper Thickness: | 18um/25um/35um/70um |
| PCB Thickness: | 0.8-2.0mm |
RF PCB PCB process
We also have the capability to produce RF (Radio Frequency) PCBs, a special type of PCB for the reliable and efficient processing of radio frequency signals. PCBs are considered RF PCBs when they operate above 100 MHz (Megahertz) and they are used in your circuit boards for sending and receiving radio signals at high frequencies.
Many advantages of RF PCB
China Dragon RF printed circuit boards are designed to eliminate signal loss, minimise EMI (electromagnetic interference) and impedance mismatch for your equipment. This is great for maintaining high-frequency signal integrity!
The substrate materials we use to produce our RF circuit boards have low dielectric constants and low loss tangents. This allows us to reduce signal attenuation and ensure efficient signal transmission at high frequencies. This amazing feature helps extend the transmission distance of your wireless communications!
Our RF boards offer precise impedance control, ensuring that the characteristic impedance of the transmission line matches the impedance of the connecting components and the transmission medium. This helps to minimise signal reflections and distortions in the RF PCB, thus improving the signal quality of your device.
We are thrilled to manufacture RF printed circuit boards for frequencies ranging from megahertz (MHz) to several gigahertz (GHz). It is this amazing ability to handle high frequencies that makes RF printed circuit boards the perfect choice for your wireless communications, radar systems, satellite communications, and more!
Our engineers are experts at designing RF printed circuit boards with components such as antennas, filters, amplifiers, and mixers laid precisely in the most logical locations on the board. This is what we call better component placement! We absolutely believe that the more precise the component placement, the better the performance and signal integrity of your equipment will be!
Our RF circuit boards are designed to reduce crosstalk, ensuring your equipment performs at its best! Crosstalk is a fascinating phenomenon that occurs when signals from neighbouring lines interfere with each other. We have the perfect solution! We use techniques such as controlled spacing, shielding and proper grounding to control this.
The manufacturing process of RF PCB
In terms of materials, we can produce RF printed circuit boards based on RF4, ROGERS, PTFE and some special ceramic materials. After a series of production processes such as copper cladding, photoresist application, photolithography, etching, drilling, plating and surface finishing, the finished products are rigorously tested and inspected for the presence of defects. After a series of production processes such as copper cladding, photoresist application, photolithography, etching, drilling, plating and surface finishing, we will carry out rigorous tests and inspections on the finished products to determine if there are any defects on the boards. Thus ensuring the accuracy of high frequency signals for you. Precision craftsmanship, excellent quality, every piece of China Dragon RF PCB, through rigorous testing.
RF PCB Applications are made in wireless communication equipment
Wireless Communication Devices
Are you looking for the perfect RF PCB for your smartphone, tablet, laptop or wearable electronic device? Or maybe you’re working on a cutting-edge cellular network signal transmission project, including 2G, 3G, 4G, 5G, Wi-Fi, Bluetooth, NFC (Near Field Communication) and other wireless protocols? Whatever your needs, China Dragon RF PCB is your one-stop shop for all things wireless! Get in touch now to get a RF PCB solution quote and let us help you stay connected!
RF PCB Applied in the RFID System
Our amazing RF PCBs are the key to seamless communication between RFID tags and readers. They can recognise RFID tags in a whole range of applications, from inventory management and asset tracking to access control and contactless payment systems. From inventory to payment, China Dragon RF PCB is the ultimate smart solution that makes life easier and management more efficient!
RF PCB Application in wireless sensor networks
Our amazing RF PCBs help to transmit sensor data wirelessly to a centralised control system. WSNs (Wireless Sensor Networks) are used in various industries for monitoring and control applications. We provide the best quality RF PCBs for your wireless sensor networks. Let the data flow freely with China Dragon RF PCB, the powerful heart of wireless sensor networks!
RF PCB Application in the satellite communication system
Our incredible RF PCBs are used in satellite communication systems for mutual communication between the ground and the satellite. They help to transmit and receive signals in satellite communications, making them an indispensable part of this cutting-edge technology. In addition, the PCBs are effective for a wide range of applications related to satellite communications, including navigation, satellite internet services and broadcasting purposes. With precise navigation, one step ahead of the Internet and clear broadcasting, China Dragon RF PCBs are revolutionizing satellite communications!
RF PCB Application in the radar system
The amazing world of radar systems is taking off! These incredible devices are being used in military, automotive, marine and meteorological applications to detect, track and image things that would otherwise be impossible to see. And the best part is that they utilise the incredible features and benefits of RF PCBs! China Dragon RF PCBs are the perfect choice for anyone looking to generate and amplify RF signals, especially for radar transmitters, receivers and signal processing units. From military to meteorological, China Dragon RF PCBs are absolutely everywhere and in everything!
RF PCB Applications in microwave devices
There’s no limit to the amazing things you can do with microwave devices! From microwave ovens to microwave links, microwave radios to microwave sensors, RF PCBs are the perfect choice for all your microwave needs. Not only that, but they’re also great for monitoring the microwave spectrum, making them ideal for a whole range of other applications, including telecoms, broadcasting and more. With China Dragon RF PCBs, you can connect the world in ways you never thought possible!
RF PCB Other application areas
And there’s more! Our RF PCBs are also used in aerospace and defence systems, medical devices, automotive and consumer electronics. They play a vital role in enabling wireless communications, signal processing and high-frequency operation in electronic devices and applications. We’ve got them all! Aerospace, defence, medical, consumer automotive – you name it, we’ve got the power of China Dragon RF PCBs!
